Suitable for shredding of wood waste, wood scrap and wood residues for example, in carpentry. Further characteristics of the shredder are: Robust construction, very reliable, easy to use, easy maintenance, low operating costs and a wide range of application areas.
The AZR 600 - AZR 800 S series provides a compact design combined with great power. These machines are best suitable for use in small or medium-sized companies which attach great importance to an optimum cost-benefit ratio. Further features include: robust design, high throughput rates, excellent reliability, operator-friendly, easy maintenance, low operating costs, wide range of applications
Our machines of the AZR 1000 - AZR 2000 Gigant series are extremely powerful: their solid construction allows for the efficient and economic shredding of bulky and large materials.
The AZR-K 800 - AZR-K 2000 Gigant series of shredders deliver powerful, reliable performance: these solidly built machines can handle even large, bulky plastic items such as sprues, sections, and purgings, shredding them into a homogenous, dust-free end product. Intelligent design in a compact unit that delivers maximum reliability guarantees cost-efficient shredding.
The AZR 60 Primus series is the starter model of the single-shaft material shredders with drawer feed. An economical series with maximum cost-benefit ratio. Other features include: Sturdy construction, high throughput rates, very reliable, easy to use, easy maintenance, lower operating costs and a wide range of possibilities for use.
The Reinbold RHZ series now incorporates even more refined details: three infeed rollers and special rails improves material infeed and makes loading the machine easier.
For shredding long and short timber, chipboard, packages and stripes, horizontal shredder series RHZ plus are used. Because auf the special link chain feeder the materials can also be supplied to the rotor in packets. Through a vibrating trough which has the same width as the horizontal shredder, the material to be crushed is offered and fed to the rotor. The material stack is captured by the chain belts, compressed and then fed to the rotor. The feed is load-based controlled. For higher throughput a rotor model with 482 mm diameter is available.
The Reinbold RHZ series is equipped with new, clever details: Three feed rollers and special strips ensure a better supply of material and easier loading of the machine. Other features include: Sturdy and protected construction (no danger of bruising), very easy to use, various supply options, easy access for easier maintenance.
New, improved and more stable strips on the feed rollers ensure optimum material-feed and constant supply of material to the rotor. The feed unit is controlled load-based, and automatically switches off when the amount of material is too large. The rotor can continue crushing trouble-free, and is not overloaded.
These machines shred waste residues and recyclable materials with ease. Ideal for reducing the volume of materials at an optimum cost-benefit ratio.
DThese machines shred waste residues and recyclable materials with ease. Ideal for reducing the volume of materials at an optimum cost-benefit ratio. Other features include: Rugged design, very reliable, operator-friendly, low running costs, wide range of applications and particularly suitable for shredding lengthy objects
The highly efficient scissors cut of the concave ground circular cuttingheads provide a very high work rate with very little effort. The knife holders are welded or mounted on the rotor and the round knives can be turned up to 8 times with just a few adjustments before having to be exchanged completely. The use of various types of knives enables jobrelated adjustment of the shredder to the material being processed.*New at Reinbold: The outer broaching knife, are replaced by the circular knife V8. This promotes a uniform crushing of materials over the entire length of the rotor.
The different diameters of the rotors: Different rotor diameters for different applications:252 mm diameter for smaller applications354 mm diameter for higher throughput 500 mm diameter for very high throughput
As larger the wrap angle of the rotor the higher is the throughput.
Powerful drives from 9.2 to 150 kW depending on the performance requirements. A high degree of efficiency due to turbo coupling (from 22 kW)
The rotor shaft is made of solid steel.
Security package with Rotary and reverse counter.
Sieve-hole-size:The default size is 15/20 mm. Also available are (in mm): 10/12, 12/15, 20/25, 25/30, 35/40, and special sizes on request.
Throughput:This depends on the feed material (long, short, wet, dry, etc.) and the screen hole size. However, expect an average of 2-4 funnel fillings per hour.
Chip removal:This can be done using a suction system, screw conveyor or a conveyor belt. The minimum air velocity of extraction units is at 28 m / sec.
For shredding long and short timber, chipboard, packages and stripes.
Three feed rollers and special strips ensure a better supply of material and easier loading of the machine. Other features include: Sturdy and protected construction (no danger of bruising), very easy to use, various supply options, easy access for easier maintenance.New, improved and more stable strips on the feed rollers ensure optimum material-feed and constant supply of material to the rotor. The feed unit is controlled load-based, and automatically switches off when the amount of material is too large. The rotor can continue crushing trouble-free, and is not overloaded.
